Team Corally CS5226 HV High Speed Servo High Volt Coreless Motor Titanium/Ballbearing/Alloy Case
Team Corally CS5226 HV High Speed Servo High Volt Coreless Motor Titanium/Ballbearing/Alloy Case is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Sign up to be the first to know when it's here
Description
Description
Are looking for some powerful control?
We have developed these servos with the racer in mind, ultimate digital power, precision and reliablity.
Features:
- Full CNC machined alloy case
- High Voltage 6.0 - 8.4V
- Titanium gears
- Ball Raced
- Coreless motor
- Ultra high speed and torque
- Water resistant
Specifications:
Motor Type: Coreless Motor
Servo Technology: Digital Ultra High Voltage
Input Voltage: 6.0V - 8.4V
Weight: 72g
Servo Type / Size: Standard
Length: 40.5 mm
Gear Material: Titanium Gears
Width: 20.5 mm
Ball Beared: Ball Beared
Height: 36.0 mm
Servo Case: CNC alloy
Servo Power - Torque: > 25 Kg/cm
Servo Speed 60°/sec: 0.05 - 0.10 Sec/60°
Protection: Waterproof
Speed 60°/Sec @ 6.0V: 0.09 Sec/60°
Speed 60°/Sec @ 7.4V: 0.08 Sec/60°
Speed 60°/Sec @ 8.4V: 0.07 Sec/60°
Torque kg/cm @ 6.0V: 18.3 Kg/cm
Torque kg/cm @ 7.4V: 22.6 Kg/cm
Torque kg/cm @ 8.4V: 25.6 Kg/cm
Connector type: JR
Spline size: 25T Spline
Thermal Protection Temperature: Waterproof
Water Protection: Waterproof
